产品信息

Part NO. Configuration BVDSS
(V)		 VGS
(V)		 VGS(TH)
(V)MAX.		 ID(A)
25℃		 RDS(ON) TYP.(mΩ) PD
(W)		 封装形式
(-)10V (-)4.5V
RZC3002S Single 30 ±20 2.5 7.0 15 20 1.5 SOP-8
RZC3202 Dual 30 ±20 2.5 7.0 15 25 2.5 SOP-8
RZC3004D Single  30 ±20 2.5 80 4 7 53 TO-252
RZC3008S Single  30 ±20 2.5 10 8 11 1.5 SOP-8
RZC3208 Dual 30 ±20 2.5 6.2 8 11 1.5 SOP-8
RZC4822 Dual 30 ±20 2.5 7.0 12 28 1.5 SOP-8
RZC3105 Single -30 ±20 -2.5 -8 12 22 1.5 SOP-8
RZC3115 Single -30 ±20 -2.5 -10 7 12 1.5 SOP-8
RZC4807 Dual -30 ±20 -2.5 -6 26 52 1.5 SOP-8
RZC4004S Single  40 ±20 2.5 10 12 17 1.5 SOP-8
RZC4204 Dual 40 ±20 2.5 10 12 17 1.5 SOP-8
RZC4005D Single  40 ±20 2.5 75 5 7 75 TO-252
RZC4005T Single  40 ±20 2.5 90 5 7 90 TO-220
RZC2023D Single  40 ±20 2.5 130 4 6 150 TO-220
RZC20N06 Single 60 ±20 2.5 20 31 --- 30 TO-252
